SPECIFICATIONS

Alternator: China Stamford,original Stamford, Marathon, Leroy Somer,Mecc Alte

Brand Name: VG

Control panel: LCD Digital Display

Cooling System Type: Water Cooling System

Engine Type: water cooled,

Frequency: 50/60HZ

Fuel consumption: 14.9L/h

Fuel tank: 8-10hours, 12hours, 24hours

Generator Type: open,silent,trailer,containerized

Model Number: VG-R28

Options: Remote Control,Battery Charger,ATS,Mobile Trailer,Soundproof Canopy,Rainproof Canopy,Current Meter,Digital Module,AMF/ATS/Container/Trailer

Output Type: AC 1/3 phase

Package: Plywood,plastic film packing

Place of Origin: Fujian, China

Protection: Overload Protection,Low Oil Shutdown,Automatic Voltage Regulation,Under-Voltage Protection

Rated Current: Depends on voltage

Rated Voltage: 110 V,220 V,230 V,240 V,380 V,400 V,480V

Speed: 1500 RPM,1800 RPM

Starting System: Auto Start,Recoil Start,Remote Start,12V DC Electric Start,24V DC Electric Start

Type: Trailer Type,Silent Type,Container Type,Super Silent Type,Open Frame,Portable Type,Mobile Type,Canopy Type

Warranty: 1years quality warranty

Emean company owned by Fujian Epos electric machinery co., Itd and Fuzhou Emean Electric Machinery Co.,Ltd LTD that is a high-tech enterprise integrating R&D, production and sales, and has always promoted high-quality power products to the international market. The products are widely sold more than 102countries and regions such as Southeast Asia South America Middle east Africa and Europe. Etc

Products Description

We have power from 10kw-2000kw,any interesting please contact with us  to quote the best price for you
Details Genset	GenSet Model	VG-R83	Type	silent(optional open)
		Frequency (Hz)	50/60	Speed rpm	1500/1800
		N.W (kg)	1250	Size (L*W*H)mm	2400*950*1230
		Fuel Con.(L/H)	14.5	Fuel capacity tank	145.8
		Running time (H)	10	Sound decibel (DB)	70-90
Details Engine	Brand	WEIFANG/RICARDO(Optional Cummins, Weichai,Yuchai, etc.)
		Model	R4105AZLD	Fuel	Diesel
		Cylinder	4	Cooling system	water
		Starter	electric	Displacement(L)	4.5
Details Alternator	Brand	China Stanford, original Stanford, Marathon, Lehua Somer, etc.
		Model	VG-R83	Type	Brushless sel-excited
		Pure copper content	100%	Efficient	92%
		Radiator	40℃-50℃	Battery	Electric start 24V charger
3 phase power	Rated power	60kw/75kva	Rated voltage	230V/380V/400V/415V
		Standby power	66kw/83kva	Rated current	94A/57A/54A/52A
Optional single phase

Our Service

Generator type

Open type

Silent type

Mobile style

SILENT CANOPY

HIGH-DENSITY WAVE SOUND-ABSORBING COTTON

1. When sound waves pass through cotton, they are reflected by countless fibers,superimposed on each other, and collide.The sound wave energy is converted into heat energy, so that the intensity of thesound wave is weakened and the sound disappears.

2. Mute sponge Mute sponge, thickness 33 mm

Product configuration and details

BRUSHLESS ALTERNATOR	ENGINE
Maintenance-free, very stable operation and voltage, low noise, suitable for use with high precision equipment and electrical equipment.	Cooperate with Cummins, Perkins, Deutz Honda and many other famous brand engines to provide you with global warranty services.

CORROSION RESISTANT RADIATOR	SOLID DAMPING FOOT	AIR FILTER
High quality and low noise radiators, with anti-rust paint to add, ensure that your machine will never old, mildew, corrosion resistance, safety.	solid damping foot is stamping forming by 3-5 mm high strength steel plate, with metal cover to protect rubber.	piston, piston ring, valve and valve seat with more than 99.5% of original filtration efficiency

Digital control panel	ELECTRONIC COMPONENTS	THICKENED BENDED UNDERFRAME
use of three remote control unit control panel,integrated digital, intelligen't technology, compact structure, simple wiring, high reliability.	Cooperate with well-known electronic component manufacturers such as Delixi and Chint to provide customers with long-life,high-quality and very accurate machines	5MM thickened bent chassis, double-layer painting, improve corrosion resistance. Prevent the unit chassis from being corroded
